Datex Ohmeda 3800 Pulse Oximeter - Refurbished
Este producto es muy dificil para encontrar o ya no está disponible de DRE, por favor vea la lista de productos relacionados abajo o pedir su experto de equipos para informacion sobre un producto similar disponible.
0 Los artículos están en tu carrito. Mirar Carrito ya.
¿Necesita asesoramiento sobre los equipos? ¡Pregunte a Nuestros Expertos!
(502) 244-6333
Descripción
The 3800 Pulse Oximeter has an easy-to-use interface and intuitive feature set, as well as advanced TruTrak® + technology, a proprietary clinical motion algorithm.
Features
- TruTrak+ technology — a proprietary clinical motion algorithm which identifies, quantifies and corrects clinical patient motion
- Always-visible Relative Perfusion Index™ (PIr) — a quick numeric value indicating pulse strength
- Plethysmographic waveform reinforces clinical decisions
- Backlit, always-on screen illuminate large numbers for fast recognition of readings
- Dedicated function keys and an always visible, simple menu system with no hidden functions
- Continuously displayed alarm limits for decisions at-a-glance
- Exceeds international durability standards through rigorous stress testing during design and manufacturing processes
- Full compatibility with all patient types and clinical situations using OxyTip®+ sensors and cables
Especificaciones
Physical Weight & Dimensions
- Height: 3.7 inches (9.4 cm)
- Width: 9.5 inches (24.4 cm)
- Depth: 8.9 inches (22.5 cm)
- Weight: 6.1 lbs (2.8 kg)
SpO2
- Calibration: Functional
- Accuracy (1 standard deviation): 70 to 100% (±2 digits); 70 to 100% (±3 digits during conditions of clinical patient motion with TruTrak+ enabled); Below 70% (unspecified)
- Range: 0 to 100%
- Resolution: 1%
Pulse Rate
- Range: 30 to 255 beats per minute (bpm)
- Accuracy (assuming a constant pulse rate): ±2% or±2 bpm (whichever is greater)
- Accuracy (during conditions of clinical patient motion): Unspecified
- Resolution: 1 bpm
Relative Perfusion Index (PIr) pulsatile value
- Range: 0.00 to 9.99
- Averaging interval: 12 seconds
- Resolution: 0.01
Alarm Limits
- Low SpO2 = OFF or 50 to 100& (preset 85%)
- High SpO2 = 50 to 100% or OFF (preset OFF)
- Low pulse = OFF or 30 to 235 bpm (preset: adult = 40 bpm, neonate = 100 bpm)
- High pulse = 30 to 235 bpm or OFF (preset: adult = 130 bpm, neonate = 200 bpm)
Alarm Silence
2 minute silence (automatic, 2 min. on start up), all mute capability.
Signal Validation
Relative Perfusion Index pulsatile value PerfTrak® waveform display.
Memory
12 hour data storage for SpO2, pulse rate and alarm conditions (1 data point every 6 seconds).
SpO2 Calculation
- 30 values per second/60 Hz
- 25 values per second/50 Hz
Display
- Digital - LED
- Waveform - Backlit LCD
SpO2 Averaging Modes
Selectable 3, 6 or 12 seconds (short, medium, long) preset = 12 seconds (long)
Diagnostics
Automatic self test on start up, continuous memory tests during operation
Outputs
Serial (SpO2, pulse rate, alarms, error messages and trend data)
Electrical Specifications
- Battery: 8 volt, 3.2 ampere-hours sealed lead-acid. Continuous charge while operating on AC
- Charge Time: 100% capacity ≈ 8 hours; 80% capacity≈ 4 hours
- Operation Time: ≈ 5.5 hours on fully charged battery
- Low Battery Indicator: "Low Battery" displayed when < 5 minutes remaining
- Overload Protection: 2 ampere 250V fuses
- Power Consumption: 15 watts typical
- Input Voltage: 100 to 240 V, 50/60 Hz
