EspañolStryker Endoscopy 988 3 CHIP Digital Camera - Refurbished
Stryker Endoscopy 988 3 CHIP Digital Camera - Refurbished
0 items are in your cart. View cart now.
Need Advice? Ask Our Experts!
(800) 462-8195
Description
The standard for capturing crystal clear digital video.
Features a range of digital and analog outputs.
Specifications
Physical Weight & Dimensions
- Unit Height: 15 inches (10.1 cm)
- Unit Width: 4 inches (24.8 cm)
- Unit Depth: 15 inches (38.1 cm)
- Camera head to camera control unit 10 feet (3 m) sealed cable or 21.3 feet (6.5 m) sealed cable (sensed by CCU)
- Imaging System: 1/3" Interline Transfer, EX view HAD CCD 752 (H) × 582 (V) pixels
Video Outputs
- Composite: PAL standard, 1.0V P-P into 75 Ohms
- Connector: BNC Coaxial
- Component: S-VHS, Y-1.0V P-P C-0.29
- Connector: 4-Pin VHS
- Component: RGB (or Y, B-Y, R-Y), 1.0V P-P into 75 Ohms
- Connector: 8-Pin DIN
- Digital Visual Interface: (DVI) Digital 1024 x 768 XGA resolution, 29-Pin DVI-I
- Serial Digital Interface: Digital SMPTE-259M BNC coaxial XGA analog
General
- Enhancement: Switchable to 8 steps
- Cable connector: Super lemo gold pin connectors
- Resolution: 950 lines
- Signal to noise ration: 72 dB
- Mounting: C-mount/standard
- Minimum illumination: < 1.0 Lux
- Auto Shutter Range: 1/50 - 1/50000
- Gain: 4 levels / 0 - 15 dB
- Power consumption: Approx. 30 W
- Input voltage range: 230 ± 10 VAC 50/60 Hz
- Total shipping weight: 13 lbs. (5.9 kg)
